Feekercn Dual 40ft Prefabricated Expandable Container Home, Symmetric Layout (White Insulated System, Full-Glass Doors, Fully Customizable)
Color
White Panels & Structure & Glass door/windows
Product Dimensions
40×20×8.3ft / unit, 2 units total
Floor Area
1600 Square Feet, 2 Units Combined
Layout Inside the tiny home
Customized Bedrooms, Bathroom, Kitchen, Living room
Specification of The Feekercn foldable house 2 units
·Layout Inside the tiny home: Customized Bedrooms, Bathroom, Kitchen, Living room
·Main Usage: Prefab Container House to live in for adults
·House Area: 1800 sqft
·External Dimensions: L40 x W20 x H8.3 ft / unit, 2 units total
·Folded Dimensions: L40 x W7.3 x H8.3 ft / unit, 2 units total
·Weight: 28000 lb
features
1. Symmetric Space Synergy
Dual 40ft expandable units are symmetrically joined, with white insulated panels defining dual living areas & bedrooms (or dual kitchens & baths). Full-glass doors unify north-south lighting, achieving over 95% space utilization — ideal for staff dormitories, campsite row housing, and symmetric functional scenarios.
2. Upgraded Energy-Efficiency System
White insulated panels with rock wool insulation, multi-chamber sealed black aluminum-clad windows, and thermal-bridge-free design at unit joints. Improves winter temperature uniformity by 40% and cuts annual energy use by 50%, ensuring stable cross-season living.
3. Modular Quick-Assembly Logic
Dual units (with expansion mechanisms) are prefabricated in the factory, enabling on-site splicing in just 1.5 days. The white frame offers 18-year anti-corrosion, and insulated panels have 12-year weather resistance, reducing lifecycle maintenance costs by 35% — supporting relocation and reuse.
4. Full-Spectrum Customization
Single units can be used independently (40ft×2), while dual units support linked expansion. Full-glass doorscan be replaced with partition walls, and internal layouts allow dual master bedrooms, dual living rooms, or dual kitchens. The white exterior accepts custom painting, suiting corporate, cultural tourism, and customized needs.
5. Cross-Scenario Adaptation
The symmetric combination covers staff dormitories (dual independent living zones), campsite row housing (dual homestay units), and emergency housing (dual functional modules). The expansion structure extends 10㎡ per unit, enabling free functional upgrades to meet large-scale scenario demands.
Internal & external facilities details
Frame Construction & Wall Panels & Roofs
The Prefab House frame construction is grey, made of thick galvanized steel square tube. Exterior and interior wall panels are made of white galvanized steel sheets, with a 75cm thickness of flame-retardant foam board in between.
Spacious Doors
Included 1 glass entrance door, 1 bathroom door, and bedroom doors as customized requirement. All doors come with standard factory configurations, all equipped with locks.
Security & Bright Windows
9 windows in total (including small 1 for bathroom), all made of aluminum alloy, in white external suspended style with built-in security bars, mosquito screens and locks.
Luxury Flooring
Made with 18mm thick cement-fiber boards, topped with 2mm thick PVC material flooring in a light wood grain pattern.
Full Set Bathroom
we provide a pre installed comprehensive dry-wet separated bathroom. The dry area comprises a toilet, adjustable hot and cold water faucet, a sink and a wall-mounted mirror.The shower area is independent and prefabricated with a showerhead and other standard accessories included
L Shaped Cabinet Set
Includes a set of white L-shaped cabinets with a white high quality sintered stone material countertop, an adjustable hot and cold water faucet, and a sink. Because of the enough space on cabinets surface, you can place some general cooking tools,microwave oven,etc.
External Water Pipe Connection
The external water pipe connections are installed ready. Included sewer pipe, drain pipe, cold water pipe and hot water pipe connections. So you need to complete the connections with your prepared main water source and sewage tank.
Electrical Configuration
The electrical setup complies with US standards and includes required distribution box, lights, switches, sockets and air conditioning sockets, with all sockets mounted at a height of 450mm from the floor.
notice info
Transportation Process
After you complete the payment and after the house prefabricated, as a special oversized item, this container home will be shipped from our factory to the nearest port via sea freight. From there, the fold out house will be delivered to your specified location via truck. Before the truck arrangement, We will contact you to schedule the delivery time for a smooth receipt.
Receiving Attention
Before purchase, you need to plan the location for receiving the mobile house, ensuring there is enough space and a flat hardened surface to unloading this prefab home. Based on the information of our container house folded dimension and weight 20000 lb. You also need to arrange for appropriate unloading machinery, such as a crane, in preparation for the scheduled delivery time.
Installation Attention
This manufactured home does not come with on-site installation workers; you will need to arrange for 6-8 people to assist with the setup. The fold up house features Hydraulic brace on both side panels, and the package includes installation tools such as Hinge pulley block and Wire rope for assembly. Please refer to the instruction and installation videos for guidance.
Customer Service
Regardless of any issues you may encounter when purchasing our container house, such as product-related concerns, transportation, delivery, installation, etc., please do not hesitate to contact our professional customer service team. We are committed to assisting you in resolving any problems you may face.
